Accelerating Data Center
Transformation

New 2nd Gen. Intel® Xeon® Scalable Processors with Intel® Optane™ DC Persistent Memory

Enabling Greater Efficiencies and Lower TCO

ASRock Rack’s entire lineup of 2nd Gen. Intel® Xeon® Scalable processors ready server platforms, providing data center intensive workload-optimized performance and hardware-enhanced security for cloud-scale computing, high-performance computing (HPC), advanced artificial intelligence (AI) and analytics for deep learning extreme workloads, driving the highest levels of operational efficiencies and lower total cost of ownership (TCO) and higher productivity for users.

Breakthrough Innovations Designed for Data-Intensive Workloads

Pairing with Intel® Optane™ DC Persistent Memory to deliver data persistence, high-capacity, advanced resiliency and powerful data encryption, ASRock Rack’s 2nd Gen. Intel® Xeon® Scalable Processor server platforms are ready to support higher individual module capacities up to 512GB offering faster system restart times and operation efficiency. The increased memory support for six memory channels with speeds up-to DDR4-2933 MHz.

Key New Features of the 2nd Gen. Intel Xeon Scalable Processors Platforms with Intel® Optane™ DC Persistent Memory

  • Up to 3.5X compute performance improvements
  • Memory speeds up-to DDR4-2933 MHz
  • Larger memory capacity with combined DDR4 and Intel® Optane™ DC Persistent Memory

ASRock Rack 2nd Gen. Intel Xeon Scalable Processors Platforms

Server / Workstation Motherboards

  • EP2C622D24LM
  • EP2C621D24LM-AB
  • EP2C622D16FM
  • EP2C621D16FM
  • EP2C621D16-4LP
  • EP2C622D16NM
  • EP2C621D16GM
  • EP2C621D8
  • EP2C622D24HM
  • EP2C621D16HM-AB
  • EP2C621D16HM2-M3
  • EP2C621D12 WS
  • EPC621D8A
  • EPC621D6I
  • EPC621D4I-2M

Server Barebones

  • 1U12XL-C622 RPSU
  • RM237-C622LM
  • 2U2G/C622
  • 2U4G-C621WS
  • 3U8G+/C621
  • 3U10G-F/C621
  • 2U4N-F/C622
EP2C622D24LM
  • L shape 16.7" x17"
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 24 DIMM Slots, Supports Six Channel, DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Intel® C622：14 x SATA3 (including 2 x M.2 ports or 2 x SATA DOM)
  • Supports 2 x PCIe 3.0 x16 (Slot 1: x16 CPU0, Slot 2: x16 from CPU1), 1 x PCIe 3.0 x8 form CPU1
  • 5 x USB 3.0 Ports (2 Ports in Rear Side, 2 ports Internal Header, 1 Port Internal Type A)
EP2C621D24LM-AB
  • L shape 16.7" x17"
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 24 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Intel® C621：14 x SATA3 (including 2 x M.2 ports)
  • Supports 2 x PCIe 3.0 x16 (Slot1: x16 CPU0, Slot 2: x16 from CPU1), 1 x PCIe 3.0 x8 form CPU1
  • 5 x USB 3.0 Ports (2 Ports in Rear Side, 2 Ports Internal Header, 1 Port Internal Type A)
EP2C622D16FM
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Support 14 x SATA3 (12 from 3 x miniSAS Connector + 2 x M.2 Ports from PCH)
  • 2 x USB 3.0 Ports
  • Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E)
EP2C621D16FM
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Support 14 x SATA3 (12 from 3 x miniSAS Connector + 2 x M.2 Ports from PCH)
  • 2 x USB 3.0 Ports
  • Integrated IPMI 2.0 with KVM and Dedicated LAN (RTL8211E)
EP2C621D16-4LP
  • EEB 12''x13''
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 14 x SATA3 6.0 Gb/s by Intel® C621 (including 2 x SATA DOM Ports and 2 x SATA Switch with 1 x M.2 NVME Ports)
  • Supports 4 x PCIe3.0 x16, 2 x PCIe3.0 x8
EP2C622D16NM
  • EEB 12''x13''
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 12 x SATA3 + 1 x SATA DOM Ports + 1 x M.2 Ports 6.0 Gb/s by Intel® C622
  • Supports 2 x PCIe3.0 x16
  • Supports Mezzanine Type A/B/C
EP2C621D16GM
  • CEB 12'' x 10.5''
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 x DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 8 x SATA3 6.0 Gb/s by Intel® C621 + 1 x M.2 port
  • Supports Dual GLAN by Intel® i350
EP2C621D8
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 8 DIMM Slots, Supports Quad Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Intel® C621：9 x SATA3 (8 port from 2 x miniSAS HD, 1 x SATA DOM ) + 1 x M.2
  • Supports Dual GLAN by Marvell 1543
  • Supports 3 x PCIe 3.0 x16, 1 x PCIe 3.0 x8
  • 4 x USB 3.0 Ports (2 Ports in Rear Side, 2 Ports Internal Header)
EP2C622D24HM
  • Half Width(OCP Blade) 6.5" x 20"
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 24 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in memory mode (Cascade Lake only)
  • Intel® C622：13 x SATA3 (by 3x miniSAS HD, 1 x SATA (share with M.2) )
  • Supports 1 x PCIe 3.0 x24, 1 x PCIe 3.0 x8
  • 1 x USB 3.0 ports
EP2C621D16HM-AB
  • Half Width 6.5” x 20”
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 10 x SATA3 6.0 Gb/s by Intel® C621(including 1 x SATA DOM port and 1 x M.2 ports)
  • Supports 2 x PCIe 3.0 x16
  • Supports Mezzanine Type A, B
EP2C621D16HM2-M3
  • Half Width(OCP Blade) 6.5" x 20"
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Intel® C621：4 x SATA3 (by miniSAS HD), 1 x M.2
  • Supports 2 x PCIe 3.0 x16, 1 x OCP 3.0 Mezzanine Slot
  • 2 x USB 3.0 Ports, 1 x mini Display Port
EP2C621D12 WS
  • EEB 12'' x 13''
  • Dual Socket P, Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 12 DIMM slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 14 x SATA3 6.0 Gb/s by Intel® C621(including 2 x SATA DOM ports and 2 x M.2 ports)
  • Supports 7®x PCIe3.0 x16 (PCIE1: x8, PCIE2/PCIE3/PCIE4/PCIE5: x16, PCIE6/PCIE7: x16/x0 or x8/x8)
EPC621D8A
  • ATX 12'' x 9.6''
  • Supports 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
  • 8 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 13 x SATA3 6.0 Gb/s by Intel® C621 (including 1 x SATA DOM port and 2 x M.2 ports)
  • Supports 2 x PCIe3.0 x16, 3 x PCIe 3.0 x8, 1 x PCIe 3.0 x4
EPC621D6I
  • Supports Single Socket Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 6 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Intel® C621 : 7 x SATA3
  • Supports Dual GLAN by Intel® integrated MAC X722 + Marvell 88E1514
  • Supports 1 x PCIe 3.0 x16
  • 2 x USB 3.0 Ports
EPC621D4I-2M
  • Supports Single Socket Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 4 DIMM Slots, Supports Quad Channel, DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Intel® C621 : 7 x SATA3
  • Supports Dual GLAN by Intel® C621 integrated MAC X722 + Marvell 88E1514
  • Supports 1 x PCIe 3.0 x16
  • 2 x USB 3.0 ports



1U12XL-C622 RPSU
  • 1U Chassis Supports 3.5” or 2.5” SATA/SAS HDD/SSD Hot-Swap Bay + 2 x 2.5’’ SATA/SAS HDD Hot-Swap Bay with 700W Redundant PSU
  • Supports Dual Socket Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • 14 x SATA3 6.0 Gb/s (12 from 3 x miniSAS connector + 2 x SATA Connector + 2 x M.2 Ports from PCH)
  • 2 x USB 3.0 Ports
  • ASPEED 2500. Integrated IPMI 2.0 with KVM, vMedia and Dedicated LAN (RTL8211E)
RM237-C622LM
  • 2U Rackmount with 1200W Redundant PSU (1+1)
  • L Shape 16.7" x17"
  • Supports Dual Socket P Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 12 x 3.5" HDDs in the Front, 2 x 2.5’’ HDDs in the Rear
  • 24 DIMM Slots, Supports Six Channel, DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports Mezzanine LAN Card*
  • Supports 1 x PCIe 3.0 x16 Expansion Slot
2U2G/C622
  • 2U Chassis support 8 x 3.5'' HDD Hot-Swap Bay + 4 x PCIe SSD and 4 Full-Height Card with 1200W Redundant PSU
  • Supports Dual Socket P Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Support 12 x SATA3 (8 from 8087 connector, 4 from SATA ports)
  • 2 x PCIe 3.0 x16 Slots, 1 x M.2 Slot, 2 x Mezzanine Slots
  • ASPEED 2400. Integrated IPMI 2.0 and KVM with Dedicated LAN
2U4G-C621WS
  • 2U Rackmount with 2000W Redundant PSU (1+1)
  • Supports Dual Socket P Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 12 DIMM slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 4 x GPGPU/MIC, 1 x PCIE
  • Supports 4 x GLAN by Marvell 88E1543
  • Supports 4 x 2.5" SATA 6GB/s HDDs (1x SATA3 HDD could support NVME* or SATA3 6GB/s HDDs) + 1 x NVME*
  • Supports 1 x PCIE Card (through riser card)
3U8G+/C621
  • 3U Rackmount with 1200W Redundant PSU (3+1)
  • Supports Dual Socket P Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 8 x GPGPU card or 8 x GPGPU/MIC
  • Supports Dual GLAN by Intel® i350
  • Supports 6 x SATA3 6.0 Gb/s or 6 x SAS 12 Gb/s HDD (Hot Swap Bay)
  • Supports 2 x PCIE Card
3U10G-F/C621
  • 3U Rackmount with 1600W Redundant PSU (3+1)
  • Supports Dual Socket P Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only)
  • Supports 10 x GPGPU/MIC
  • Supports Dual GLAN by Intel® i350
  • Supports 6 x SATA3 6.0 Gb/s or 6 x SAS 12 Gb/s / including 2 x NVME* ( cable optional) Hot Swap Bay
  • Supports 2 x PCIE Card
2U4N-F/C622
  • 2U Chassis with 4 Nodes, 1600W Redundant (1+1) PSU
  • Supports Dual Socket P Intel® Xeon® Scalable Processors / 2nd Gen. Intel® Xeon® Scalable Processors Per Node
  • 16 DIMM Slots, Supports Six Channel DDR4 2933/2666/2400/2133 RDIMM/LR DIMM, Intel® Optane™ DC Persistent Memory in Memory Mode (Cascade Lake only) Per Node
  • Supports 4 x 2.5" HDD/SSD Per Node (all SATA or 2 x NVME* + 2 x SATA) Per Node
  • Supports 2 x PCIe3.0 x16 (Low Profile) Per Node
  • Integrated IPMI 2.0 and KVM with Dedicated LAN Per Node
  • Supports Optional Mezzanine Type-C LAN Card MP-4227R2/MP-1543R4
