| Система | |
| Форм-фактор | - 1U Rackmount |
| Шасси | - 1U12L |
| Габариты | - 860 x 438.5 x 43.2 mm (33.9" x 17.3" x 1.7") |
| Совместимые платы | - EPYCD8-2T |
| Передняя панель | |
| Buttons | - Power On/Off button - UID button - System reset button |
| LEDs | - 1 x Power status LED - 1 x LAN activity LED - 1 x HDD status LED |
| I/O Ports | - 2 x USB 3.0 ports |
| Внешний дисковый отсек / Накопитель | |
| Передний отсек | - 2 Hot-Swappable Bay for 2.5” NVME SSD |
| Передняя Backplane | - Dual single Backplanes for each drive |
| Internal Side | - 12 Bay multi-function Hot-Swappable Bay for 3.5” or 2.5” SATA/SAS HDD/SSD* *2.5” SATA/SAS HDD/SSD is going to be supported soon. Please contact our sales representatives for the information of when it is available. *A raid card is required to support SAS HDD/SSD. How many HDD/SSD are supported vary depending on the type of raid card you use. |
| Internal Side Backplane | - 3x Quad ports Backplane for drives* *SFF-8482 connector |
| Блок питания | |
| Тип | - 1U, Redundant |
| Выходная мощность | - 700W |
| Системный вентилятор | |
| Вентилятор | - 40 x 28 mm Fan x6 |
| Параметры материнской платы | |
| Форм-фактор | - ATX |
| Габариты | - 12'' x 9.6'' (305 mm x 244 mm) |
| Блок процессора | |
| CPU | - AMD EPYC™ 7002/7001 series processor family |
| Разъем | - Single Socket SP3 (LGA4094) |
| Память | |
| Емкость | - 8 DIMM slots |
| Тип | - Eight Channel DDR4 memory technology - Supports DDR4 RDIMM and LRDIMM |
| DIMM Size Per DIMM | - RDIMM: 32GB, 16GB, 8GB - LRDIMM: 128GB, 32GB |
| Max. DIMM Frequency | - RDIMM: 2666/2400MHz - LRDIMM: 2666/2400MHz |
| Напряжение | - 1.2V |
| Слоты расширения PCIe | |
| PCIe x 16 | - 1 PCIe3.0 x16 |
| Накопитель SATA/SAS | |
| OCuLink for U.2 | - 2 |
| Ethernet | |
| Интерфейс | - 10000/1000 /100 /10 Mbps by Intel® X550 |
| Контроллер GbE LAN | - 2 x RJ45 10G base-T by Intel® X550 - 1 x RJ45 Dedicated IPMI LAN port by RTL8211E - Supports Wake-On-LAN - Supports Energy E_cient Ethernet 802.3az - Supports Dual LAN with Teaming function - Supports PXE - LAN1 supports NCSI |
| Управление сервером | |
| Контроллер BMC | - ASPEED AST2500 |
| IPMI Dedicated GLAN | - 1 x Realtek RTL8211E for dedicated management GLAN |
| Функции | - Watch Dog - NMI |
| Графика | |
| Контроллер | - ASPEED AST2500 |
| VRAM | - DDR4 128Mb |
| Вход-выход задней панели | |
| Порт VGA | - 1 x D-Sub |
| Порты USB 3.0 | - 2 Type-A (USB3.2 Gen1) |
| Порт Lan | - 2+1 RJ45 Gigabit Ethernet LAN port - LAN Ports with LED (ACT/LINK LED and SPEED LED) |
| Последовательный порт | - 1 x COM port |
| UID Button/UID LED | - 1 |
| Внутренние разъемы | |
| SATA DOM | - 1 |
| M.2 | - 2(M2_1: 2230/2242/2260/2280, SATA/PCIE(X4); M2_2:2230/2242/2260/2280/22110, SATA/PCIE(X4)) |
| Front LED | - 1 |
| Auxiliary Panel Header | - 1 (includes chassis intrusion, location button & LED, and front LAN LED) |
| TR1 Header | - 1 |
| TPM | - 1 |
| IPMB | - 1 |
| USB 3.2 (Gen1) Header | - 1 (19-pin, 2 USB3.2 Gen1) |
| LED на плате | |
| Port 80 LED | - 1 |
| Fan Fail LED | - 1 (only Fan Fail LED) |
| BIOS | |
| Тип BIOS | - 32MB AMI UEFI Legal BIOS |
| Особенности BIOS | - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8 Support - ASRock Rack Instant Flash |
| Аппаратный мониторинг | |
| Температура | - CPU Temperature Sensing - MB/TR1/Card side Temperature Sensing |
| Вентилятор | - CPU/Rear/Front Fan Tachometer - CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU Temperature) - CPU/Rear/Front Fan Multi-Speed Control |
| Напряжение | - Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3V/5V/12V, +BAT, 3VSB, 5VSB |
| Совместимые ОС | |
| ОС | Microsoft® Windows® - Server 2012 R2 (64 bit) - Server 2016 (64 bit) Linux - RedHat Enterprise Linux Server 6.9 (64 bit) / 7.3 (64 bit) - CentOS 6.9 (64 bit) / 7. 3 (64 bit) - SUSE Enterprise Linux Server 11 SP4 (64 bit) / 12 SP2 (64 bit) - Ubuntu 16.04 (64 bit) / 17.04 (64 bit) - CITRIX XenServer 7.5 Virtual: - VMWare® ESXi 6.5 u1 - vSphere 6.5 u1 * Please refer to our website for the latest OS support list. |
| Рабочая обстановка | |
| Температура | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
