Ready for the latest Intel® Xeon® E-2300 Series Processors with ASRock Rack C256/C252 Motherboards

With up to 8-cores and Gen 12 Graphics supports, the Intel® Xeon® E-2300 series processors which are designed with the whole new structure based on the LGA1200 will be the popular platform for the small business, design studio and freelancers. Offering the enterprise-class reliability and performance, this entry level segment provides a possibility for small business to enhance their server and workstation with an affordable budget. Considering the space size and flexibility, ASRock Rack aimed the same target audience by offering some different server and mATX , mini-ITX motherboards for the best combination.

Security Enhanced

Even the entry Server Solutions could be secured by the enterprise-level technology, the Build-in Intel® SGX, especially for the demands of private Cloud or small business NAS.

Efficiency Over-deliver

The motherboards are designed for the legacy applications by their versatile interface and full specifications. Moreover, based on the backward compatible I/O, the new interface are delivering new supporting and benefits, such as PCIe Gen4 and higher memory frequency up to DDR4-3200.

Performance Optimized

Supporting the heavily threaded, the Intel® Xeon® E-2300 series processors are optimized their performance by 16% with higher frequency and power levels.

1U4LW-C252
  • 1U Rackmount with single 400W PSU
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM Memory
  • 1 FH PCIe4.0 x16
  • 4 Hot-swap 3.5'' SATA drive bays, 2 fixed 2.5'' SATA drive bays, 1 Slim ODD (optional)
  • Supports 1 M.2 (PCIe3.0 x2 or SATA 6Gb/s)
  • 2 RJ45 (1GbE) by Intel® i210
  • VGA, HDMI, Remote Management (IPMI)
1U2E-C252
  • 1U Rackmount with single 315W PSU
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM Memory
  • 2 Hot-swap 2.5'' SATA/NVMe drive bays, 1 fixed 3.5'' SATA drive bays or 1 Slim ODD (optional)
  • Supports 1 M.2 (PCIe3.0 x2 or SATA 6Gb/s)
  • 2 RJ45 (1GbE) by Intel® i210
  • VGA, HDMI, Remote Management (IPMI)




E3C256D4U-2L2T
  • Micro-ATX (9.6" x 9.6")
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM Memory
  • 1 PCIe4.0 x16, 1 PCIe4.0 x4, 1 PCIe3.0 x1
  • Supports 1 M.2 (PCIe3.0 x4 or SATA 6Gb/s), 1 M.2 (PCIe3.0 x4)
  • 8 SATA 6Gb/s
  • 2 RJ45 (10GbE) by Intel® X710-AT2
  • 2 RJ45 (1GbE) by Intel® i210
  • VGA, HDMI, Remote Management (IPMI)
E3C252D4U-2T
  • Micro-ATX (9.6" x 9.6")
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM Memory
  • 1 PCIe4.0 x16, 1 PCIe4.0 x4, 1 PCIe3.0 x1
  • Supports 1 M.2 (PCIe3.0 x2 or SATA 6Gb/s)
  • 6 SATA 6Gb/s
  • 2 RJ45 (10GbE) by Intel® X710-AT2
  • VGA, HDMI, Remote Management (IPMI)
E3C252D4U
  • Micro-ATX (9.6" x 9.6")
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM Memory
  • 1 PCIe4.0 x16, 1 PCIe4.0 x4, 1 PCIe3.0 x1
  • Supports 1 M.2 (PCIe3.0 x2 or SATA 6Gb/s)
  • 6 SATA 6Gb/s
  • 2 RJ45 (1GbE) by Intel® i210
  • VGA, HDMI, Remote Management (IPMI)
E3C256D2I
  • m-ITX (6.7" x 6.7")
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 2 DIMM slots (1DPC), supports DDR4 ECC/non-ECC UDIMM Memory
  • 1 PCIe4.0 x16
  • Supports 2 OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s)
  • Supports 1 M.2 (PCIe4.0 x4)
  • 8 SATA 6Gb/s
  • 1 RJ45 (1GbE) by Intel® i210
  • 1 RJ45 (1GbE) by Intel® i219-LM
  • Supports ATX PSU or 12V DC-in
  • Remote Management (IPMI)
E3C256D4I-2T
  • m-ITX (6.7" x 6.7")
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC SODIMM Memory
  • 1 PCIe4.0 x16
  • Supports 2 OCuLInk (PCIe3.0 x4 or 4 SATA 6Gb/s)
  • Supports 1 M.2 (PCIe4.0 x4)
  • 8 SATA 6Gb/s
  • 2 RJ45 (10GbE) by Intel® X550
  • Supports ATX PSU or 12V DC-in
  • Remote Management (IPMI)
E3C256D4ID-2T
  • Deep mini-ITX (6.7" x 8.2")
  • Supports Intel® Xeon® E-2300 and Pentium® Series Processors
  • 4 DIMM slots (2DPC), supports ECC/non-ECC UDIMM Memory
  • 1 PCIe4.0 x16
  • Supports 2 OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s), 1 OCuLink (PCIe3.0 x4)
  • Supports 1 M.2 (PCIe4.0 x4), 1 M.2 (PCIe3.0 x4)
  • 8 SATA 6Gb/s
  • 2 RJ45 (10GbE) by Intel® X710-AT2
  • Supports ATX PSU or 12V DC-in
  • Remote Management (IPMI)
